Description

SPESIFIKASI :

Model TE-10 HD
Operating Weight 1.7 T
Engine Model YANMAR 3TNV70 (Euro V)
Rated Power 10.3/200 kw/r/min
Max. Flow 49.5 L/min
Working Pressure 20.6 Mpa
Travel Speed 2.1 km/h
Swing Speed 8.5 r/min
Hydraulic Pump Model NACHI
Bucket Capacity 0.045 (m³)
Fuel Tank Capacity 22 L
Hydraulic Oil Tank Capacity 21 L
Max. GHradeability 58% / 30°
Ground Pressure 28 Kpa
Arm Digging Force 8.6 kn
Bucket Digging Press 13.5 kn
Swing / Travel Motor Model EATON
Overall Dimension 3707 x 1000 x 2424 mm
Additional information
Weight 1700 kg
Dimensions 370.7 × 100 × 242.4 cm
